Socket AM5, B850 Chipset, Supports 7000/8000/9000 series AMD Ryzen, 4x DIMM Slots, DDR5 8200MHz (OC), PCIe Gen 5, 4x SATA 6Gb/s connectors, 3x M.2 Slot, 2.5GB LAN, USB Type-C, WIFI 7, ATX

• Twin 14+2+2 Phases Digital VRM with DrMOS
• Dual Channel DDR5：4*DIMMs
• PCIe Gen5 x16 with PCIe UD Slot & EZ-Latch Plus
• M.2 Gen5 with EZ-Latch Plus, Fully Covered MOSFET Heatsinks
• Wi-Fi 7 with WIFI EZ-Plug & Directional Antenna
• 2.5GbE LAN, Q-Flash Plus

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Specifications

Wi-Fi & LAN	LAN Yes LAN Ports 1x 2.5 Gbit/s Wi-Fi / Bluetooth Yes Wi-Fi Standard Wi-Fi 7 Bluetooth Standard 5.4 Wi-Fi Chip Realtek RTL8922AE CPU CPU Manufacturer AMD CPU Socket AM5 Lighting Lighting / RGB Yes Back Connect Back Connect No Form Factor Motherboard Form Factor ATX Colour Primary Colour Black Motherboard Motherboard Chipset AMD B850 Dual BIOS No Built-In I/O Shield Yes Memory Max. Memory 256 GB Memory Type DDR5 Memory Form Factor DIMM Max. Memory Speed (Standard) 5200 MT/s Max. Memory Speed (OC) 8200 MT/s EEC Support No Memory slots 4x Performance Profile AMD EXPO, Intel XMP Fan Header 4 Pin Fan Connectors 6 Expansion Slots PCIe x16 slots (total) 3 PCIe 5.0 x16 mechanical slot 1 PCIe 3.0 x1 mechanical slot 2 Internal Ports CPU Power Supply 1x 4-Pin + 1x 8-Pin USB 3.0 / 3.1 / 3.2 (internal) Type C Header 1 USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports 1 USB 3.0 (internal) Header 1 USB 3.0 (internal) Possible Ports 2 USB 2.0 (internal) Header 2 USB 2.0 (internal) Possible Ports 4 RGB / LED connectors 1x RGB (4-Pin 5050 12VGRB), 3x Digital RGB (3-Pin 5VDG) Front Panel Audio Header Yes SPI TPM Header Yes External Ports USB 3.1 (external) Type C 1 USB 3.1 (external) Type A 2 USB 3.0 (external) Type A 5 USB 2.0 (external) Type A 4 Display Connectors Display Port (1x) Cooling M.2 Heatsinks Yes VRM Heatsinks Yes Storage Ports M.2 PCIe 4.0 x4 2 M.2 PCIe 5.0 x4 1 SATA 6G (internal) 4
LAN	Yes
LAN Ports	1x 2.5 Gbit/s
Wi-Fi / Bluetooth	Yes
Wi-Fi Standard	Wi-Fi 7
Bluetooth Standard	5.4
Wi-Fi Chip	Realtek RTL8922AE
CPU Manufacturer	AMD
CPU Socket	AM5
Lighting / RGB	Yes
Back Connect	No
Motherboard Form Factor	ATX
Primary Colour	Black
Motherboard Chipset	AMD B850
Dual BIOS	No
Built-In I/O Shield	Yes
Max. Memory	256 GB
Memory Type	DDR5
Memory Form Factor	DIMM
Max. Memory Speed (Standard)	5200 MT/s
Max. Memory Speed (OC)	8200 MT/s
EEC Support	No
Memory slots	4x
Performance Profile	AMD EXPO, Intel XMP
4 Pin Fan Connectors	6
PCIe x16 slots (total)	3
PCIe 5.0 x16 mechanical slot	1
PCIe 3.0 x1 mechanical slot	2
CPU Power Supply	1x 4-Pin + 1x 8-Pin
USB 3.0 / 3.1 / 3.2 (internal) Type C Header	1
USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports	1
USB 3.0 (internal) Header	1
USB 3.0 (internal) Possible Ports	2
USB 2.0 (internal) Header	2
USB 2.0 (internal) Possible Ports	4
RGB / LED connectors	1x RGB (4-Pin 5050 12VGRB), 3x Digital RGB (3-Pin 5VDG)
Front Panel Audio Header	Yes
SPI TPM Header	Yes
USB 3.1 (external) Type C	1
USB 3.1 (external) Type A	2
USB 3.0 (external) Type A	5
USB 2.0 (external) Type A	4
Display Connectors	Display Port (1x)
M.2 Heatsinks	Yes
VRM Heatsinks	Yes
M.2 PCIe 4.0 x4	2
M.2 PCIe 5.0 x4	1
SATA 6G (internal)	4
