BX8071514600KF, 14/20 Cores / Threads, 3.50GHz Clock Speed, 5.3GHz Single Core Max Turbo, 44mb Cache, 125W TDP, Dual Channel DDR4/DDR5 Controller, Onboard Graphics: No, 3 Year Warranty 14th Gen Intel® Core™ i5-14600K desktop processor. Featuring Intel® Adaptive Boost Technology, Intel® Thermal Velocity Boost, Intel® Turbo Boost Max Technology 3.0, and PCIe 5.0 & 4.0 support, DDR5 and DDR4 support, unlocked 14th Gen Intel® Core™ i5 desktop processors are optimized for enthusiast gamers and serious creators and help deliver high performance. Compatible with Intel® 700 Series and Intel® 600 Series Chipset based motherboards. 125W Processor Base Power.


Features:
- Intel is driving next level performance with Raptor Lake
- Increased processor core count - Up to 14 (6P+8E) processor cores with up to 20 threads
- Improved P-core performance
- Increased Intel Smart Cache (L3) and L2 cache on Intel Core i5 Desktop processors and above
- Extended performance hybrid architecture2 to all Intel Core i5 Desktop processors and above
- Up to 192GB DDR5-5600 memory, up to 192GB DDR5-5200 memory and up to 192GB DDR4-3600 memory
- 20 lanes of CPU PCIe* Gen 5.0; Up to 20 lanes of PCH PCIe* Gen 4.0
- Integrated Intel Wi-Fi 6E support
- Four simultaneous 4K displays, media and graphics features
- Core & memory overclocking
- Processor compatibility with Intel® 600 and 700 Series chipset-based motherboards
- Intel® Deep Learning Boost (VNNI) and Intel Gaussian & Neural Accelerator (GNA) 3.0 support
- Security Feature Enhancements targeting Business Computing


Specification:
- P-Core Base Frequency: 3.5GHz
- E-Core Base Frequuency: 2.6GHz
- Socket: LGA1700
- Intel Smart L3 Cache: 24MB
- L2 Cache: 20MB
- Processor Cores: 14 (6P + 8E)
- Processor Threads: 20
- Memory Support: DDR4 3600MHz & DDR5 5200-8000MHz
- Intel Thermal Velocity Boost Frequency: NA
- Intel Turbo Boost Max Technology 3.0 Frequency: NA
- P-Core Max Turbo Frequency: 5.3GHz
- E-Core Max Turbo Frequency:: 4.0GHz
- CPU PCIe Lanes:20
- Unlocked: YES
- Chipset: Intel 600 & 700 Series Compatible
- Base Power: 125W
- Maximum Power: 181W
- Intel SIPP
- Intel vPRO
- ISM
- Warranty: 3yr

Specifications

CPU	CPU Manufacturer Intel CPU Series Intel Core i5 CPU Socket 1700 CPU Architecture Intel Raptor Lake-S CPU Cores 14 CPU Threads 20 Performance Cores 6 Efficiency Cores 8 Hyperthreading / Multithreading Yes Memory Controller dual channel L2-Cache 20 MB L3-Cache 24 MB TDP 125 W CPU Cooler Included No CPU Packaging boxed / retail Integrated GPU No Thermal Specifications Max. TDP 181 W Clock Speeds Max. CPU Clock (Base) 3.5 GHz Max. CPU Clock (Turbo / Boost) 5.3 GHz Max. P-Core Clock (Base) 3.5 GHz Max. P-Core Clock Single Core (Turbo) 5.3 GHz Max. E-Core Clock (Base) 2.6 GHz Max. E-Core Clock Multi Core (Turbo) 4 GHz Memory Memory Compatibility DDR5, DDR4 System Memory Subtype UDIMM Max. Memory Speed (Standard) 5600 MT/s EEC Support Yes Compatibility Compatibility Note Please refer to the manufacturer's compatibility information. You can find the latest overview on the manufacturer's website. Connectivity PCIe-5.0-Lanes 16 PCIe-4.0-Lanes 4
CPU Manufacturer	Intel
CPU Series	Intel Core i5
CPU Socket	1700
CPU Architecture	Intel Raptor Lake-S
CPU Cores	14
CPU Threads	20
Performance Cores	6
Efficiency Cores	8
Hyperthreading / Multithreading	Yes
Memory Controller	dual channel
L2-Cache	20 MB
L3-Cache	24 MB
TDP	125 W
CPU Cooler Included	No
CPU Packaging	boxed / retail
Integrated GPU	No
Max. TDP	181 W
Max. CPU Clock (Base)	3.5 GHz
Max. CPU Clock (Turbo / Boost)	5.3 GHz
Max. P-Core Clock (Base)	3.5 GHz
Max. P-Core Clock Single Core (Turbo)	5.3 GHz
Max. E-Core Clock (Base)	2.6 GHz
Max. E-Core Clock Multi Core (Turbo)	4 GHz
Memory Compatibility	DDR5, DDR4
System Memory Subtype	UDIMM
Max. Memory Speed (Standard)	5600 MT/s
EEC Support	Yes
Compatibility Note	Please refer to the manufacturer's compatibility information. You can find the latest overview on the manufacturer's website.
PCIe-5.0-Lanes	16
PCIe-4.0-Lanes	4
